Main Product: PTFE wire



PTFE2800-07S (Xianduan Style number) is used in high temperature electronic applications or where abrasion resistance is required. It has excellent thermal aging, solder damage, flame, and moisture resistance. PTFE resists solvents, grease, ozone and other chemicals. Low power loss, ideal for high frequency applications. Recommended for critical applications.



• Conductor: Silver-plated stranded copper wire

• Insulation: Extruded PTFE Insulation

• Temperature Range: -65°C to +200°C (-85°F to +392°F)

• Compliances: MIL-W-16878E/4 Type E, MIL-STD-104, Passes UL VW-Flame Test and Birdcage Test, RoHS Compliant

• Features: Excellent thermal aging, solder damage, flame, and moisture resistance. Resists solvents, grease, ozone and other chemicals. Low power loss, ideal for high frequency applications.

• Voltage Rating: 600 VAC



Other Products



• Conductor: bare copper/tinned copper/silver plate copper/nickel plated copper

• Insulation: PVC wires, XLPVC wires, XLPE wire, SILICONE wire, TFE wires, PTFE wires, ETFE wires, PFA wires, TEFZEL wires, PVDF wires, FEP wires, MFA wires, SAE automotive wires, MTW wires, FIXTURE wires.

• Certifications: UL, CUL, CCC, VDE CSA etc.
